1310/1490/1550 Filter Wavelength Division Multiplexer(FWDM)

Price:	25.0~400.0 USD
Payment Terms:	T/T
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: FY-WDM

Production Capacity: 2000 PCS

Delivery Date: 7 days

Means of Transport: Air

Packing: CARTON

Brand Name: Flyin

Wide Operating Wavelength Range
Low Insertion Loss
Ultra Flat Wide Passband
High Channel Isolation
High Stability and reliab

Flyin Optronics' Micro-Optical WDM utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging. It provides low insertion loss, high channel isolation, low temperature sensitivity and epoxy free optical path.

Features

l Wide Operating Wavelength Range

l Low Insertion Loss

l Ultra Flat Wide Passband

l High Channel Isolation

l High Stability and reliability

l Epoxy-free on Optical Path

Applications

l Testing Instruments

l FTTH Tri-Play System

Performance Specifications

Parameter		FWDM 4/35	FWDM 5/34	FWDM 34/5
Pass Band Wavelength Range (nm)		1480~1500	1540~1560	1260~1360&1480~1500
Reflection Band 1 Wavelength Range (nm)		1260~1360	1260~1360	1540~1560
Reflection Band 2 Wavelength Range (nm)		1540~1560	1480~1500
Insertion loss (dB)	Reflect Channel	≤0.6
	Pass Channel	≤0.8
Pass Band Rippler (dB)		<0.3
Isolation	Reflect Channel	>15
	Pass Channel	>30
Insertion Loss Temperature Sensitivity (dB/℃)		<0.005
Polarization Dependent Loss (dB)		<0.1
Polarization Mode Dispersion (ps)		<0.1
Directivity (dB)		>50
Return loss (dB)		>50
Maximum Power Handling (mW)		1000
Operating Temperature (℃)		-20~+80
Storage Temperature (℃)		-40~+85
Package Dimension (mm)		Φ5.5x34 (L38 for 900um Loose tube)

Specifications may change without notice.

Above specification are for device without connector.

Ordering Information

MWDM	X	X	X	XX
	Wavelength	Fiber Type	Fiber Length	In/Out Connector
4/35=1490 pass 1310&1550 reflect 5/34=1550 pass 1310&1490 reflect 34/5=1310&1490 pass 1550 reflect	1=Bare fiber 2=900um loose tube	1=1m 2=2m	0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=ST 6=LC S=Specify

MWDM

Wavelength

Fiber Type

Fiber Length

In/Out Connector

4/35=1490 pass

1310&1550 reflect

5/34=1550 pass

1310&1490 reflect

34/5=1310&1490 pass

1550 reflect

1=Bare fiber
